Il nuovo sagomatore LEDko FullSpectrum 6 HD, realizzato con elettronica HD e un nuovo schermo LCD, è l'evoluzione del nostro LEDko FullSpectrum 6. Il display LCD rende ancora più semplice e rapida l'impostazione delle principali funzioni del proiettore, ma la vera rivoluzione è l'elettronica HD, che permette la dimmerazione e la miscelazione dei 6 colori a 20 bit. Caratteristiche principali: • Nuovo display LCD con pulsanti aggiuntivi per il settaggio rapido delle funzioni base del proiettore • Miscelazione a 6 colori (Rosso, Verde, Blu, Bianco, Lime, Ambra) a 20 bit • CCT da 2.700 a 6.500 K con Indice di Resa Cromatica > 90 • Dimmer elettronico a 16 bit con 4 curve selezionabili (esponenziale, logaritmica e lineare e halo) processate in digitale a 20 bit • Funzionamento flicker-free garantito (frequenza di aggiornamento LED a 20.000 Hz) • Lenti Fresnel e PC disponibili

If you want to switch your TV studio or theatre from halogen to LED, the ReLite Series is the perfect retrofit solution for you. Easy and quick upgrade, excellent white light quality, huge power savings with almost no heat generation and long life LED lamps are just some of the advantages offered by our ReLite Series. The internal microprocessor and HD electronics mark the difference between the standard ReLite and the new ReLite HD, designed to retrofit 1 K and 2 K traditional incandescent fixtures. The advanced intelligence of this device comes from the interconnection between these new technologies and the internal thermal sensor, who detects and controls the temperature inside the fixture while operating and constantly stabilizes the LED’s luminous flux. . In this way even if the temperature inside the fixture raises and lowers due to a change in the dimming mode, the new ReLite HD saves the initial temperature and maintains it. This guarantees a more stable light output compared to the first ReLite version (with a max power consumption of 160 W). The ReLite Led HD features also 2 DIP switches: the first one allows the adjustment of the fan speed (100% or 75% of the maximum fan speed for quiet environments) and the second one the reset of the temperature in case a user needs to use the same ReLite HD in different fixtures. Linear and smooth dimming from 1% to 100% (stability of the light output guaranteed starting from 10/15% of the dimmer channel, depending on the installation conditions) plus flicker-free performance make it the ideal retrofit solution for broadcast and theatre lighting. The possibility to choose between different dimming curve options and the easy firmware upgrade complete this product. Available in two different versions – Tungsten and Daylight – with a CRI greater than 95, for a faithful and realistic color rendering.

Coemar illuminates a new adaptation of one of the most award-winning musicals in Broadway history - "A CHORUS LINE" - with Reflection LEDko FullSpectrum 6 HD.

Lighting Designer - FRANCESCO VIGNATI | Official Photographer - LKV Photo Agency LUCA VANTUSSO.

Teatro Nazionale CheBanca! - Milan (2019)



Otello HD è l’ultima innovazione Coemar nel campo dei proiettori con lente Fresnel.

Pensato per soddisfare tutte le esigenze nel campo dell’illuminazione professionale, dalla televisione al teatro, Otello HD riassume tutte le caratteristiche tradizionali di un proiettore Fresnel: la lente produce il tipico fascio di luce dai contorni morbidi in grado di creare un campo luce diffuso ed uniforme.

La vera evoluzione tecnologica consiste nell’utilizzo dell’elettronica HD, che garantisce una dimmerazione omogenea a 20 bit e un migliore mix cromatico dei LED a 6 colori - Rosso, Verde, Blu, Ciano, Lime, Ambra.

Otello HD è dotato di zoom motorizzato per un controllo da remoto del fascio luminosoancora più semplice e veloce. Sarà infattipossibile regolare l'angolo di apertura direttamente tramite console DMX e adattare la luce a ogni contesto: dal fascio più stretto per una luce concentrata ad un fascio ampio per una luce diffusa.

Le tonalità di bianco possono essere regolate con precisione da 2.800 a 6.500 K nella versione VariWhite e da 2.700 K a 6.500 K nella versione FullSpectrum. Il bilanciamento verde-magenta, presente nella versione FullSpectrum, permette un controllo ancora più accurato del bianco e dà la possibilità di uniformare la luce del proiettore a quella emessa da altri prodotti per adattarla alle tonalità della pelle e alla luce ambientale. E’ inoltre possibile correggere la saturazione dei colori tramite un canale DMX dedicato. Per facilitare l'utente nella selezione della tonalità colore sono presenti delle librerie colore preimpostate, che possono essere personalizzate e memorizzate all'interno del proiettore.

Elettronica HD e zoom motorizzato, uniti ad un intuitivo schermo LCD e un moderno design Made in Italy, fanno di Otello HD il proiettore Fresnel più tecnologicamente avanzato presente sul mercato.

Le versioni FullSpectrum e Variwhite sono disponibili anche con zoom manuale. Le versioni Tungsten e DayLight sono invece disponibili in versione base, senza elettronica HD e zoom motorizzato.

Prodotto disponibile anche con forcella con comando a palo (pole operated).

28 LEDko TM Variwhite - Coemar moving head LED lights - illuminate the italian TV studios of the most famous cooking show in the world, Masterchef 9. This motorized version of the current LEDko Led Profile, reduces the burden of manually adjusting the setting of the fixtures once mounted on the rigging infrastructure and makes the control of the lights easier.

Located at the heart of the Opera Disctrict, the Dubai Opera is the city’s first multi-format performing arts theatre and the destination for quality entertainment productions and performances. We are really proud to illuminate this majestic theatre with our ParLite Led wash lights.

SoftLite Led, the 250 W diffuse led light projector equipped with the revolutionary and unique reflected illumination system. Thanks to its innovative optical system, SoftLite Led delivers an extremely uniform output with incredibly soft shadows and a perfect color mixing (RGBW version): this is the reason why this fixture is considered the perfect LED replacement for traditional cyclorama or fill lights. SoftLite Led provides different DMX control modes to allow the quick setup of the fixture in various application situations and a smooth 16 bit dimming with a choice of 3 curve options available (linear, logarithmic and exponential). The PWM frequencies can be adjusted from 600 up to 19.000 Hz either on board or via DMX for flicker-free performance and this makes the SoftLite Led the perfect tool for professional lighting both in broadcast and theatre applications. The extruded aluminum and steel housing integrates 3 different fan speed setting (low, auto, DMX regulated), that enables a low noise operation while a bright LED display permits an easy and intuitive configuration. The double dissipation system with air forced efficient heat pipe cooling and the adjustable fan ensure optimum operation without any danger of overheating. The fixture comes with either a manual or pole operated yoke. A set of accessories is also available to allow the control of the beam. Available in three different versions: Tungsten, RGBW, VariWhite.

ILLUMINAZIONE PROFESSIONALE

Coemar Lighting progetta, produce e commercializza prodotti per l’illuminazione professionale dal 1933.

La società opera a livello mondiale nel segmento delle “luci intelligenti”, proiettori ad alta tecnologia e con particolari funzionalità utilizzati in diversi ambiti dell’intrattenimento e dell’architettura: concerti, studi televisivi, teatri, musei, fashion show, eventi aziendali e molto altro.

ll marchio Coemar è riconosciuto come uno dei più prestigiosi nel mercato per quanto riguarda la produzione di proiettori di alta gamma, grazie alle elevate prestazioni, la qualità e l’innovazione che da sempre contraddistinguono i nostri prodotti.

Coemar è stata tra le prime realtà al mondo a comprendere le grandi potenzialità della tecnologia a LED, anticipandone l’applicazione nell’ambito dell’illuminazione. L’azienda ha investito risorse economiche e professionali per promuovere lo sviluppo continuo di questa tecnologia, arrivando ad ottenere diversi premi e riconoscimenti internazionali.

La direzione della società ha sede a Castiglione delle Stiviere (MN) e si avvale di una rete distributiva sparsa in più di 50 paesi in tutto il mondo.

LIGHT EMOTIONS.

Since 1933 your best partner in LIGHT EMOTIONS

select your field:

Coemar ParLite Led illuminates Dubai Opera

Dubai, 2016

SEE PROJECT

Coemar LEDko Daylight lights up the Duomo in Milan

Milan, 2017

SEE PROJECT

LEDko FullSpectrum 6 for "Mary Poppins" musical

, 2017

SEE PROJECT
ProductParLite Led
ProductLEDko
ProductLEDko

select your business

HIGHLIGHTS

  • LEDko FullSpectrum 6 HD

    Il nuovo sagomatore LEDko FullSpectrum 6 HD, realizzato con elettronica HD e un nuovo schermo LCD, è l’evoluzione del nostro LEDko FullSpectrum 6.
    Il display LCD rende ancora più semplice e rapida l’impostazione delle principali funzioni del proiettore, ma la vera rivoluzione è l’elettronica HD, che permette la dimmerazione e la miscelazione dei 6 colori a 20 bit.

    Caratteristiche principali:
    • Nuovo display LCD con pulsanti aggiuntivi per il settaggio rapido delle funzioni base del proiettore
    • Miscelazione a 6 colori (Rosso, Verde, Blu, Bianco, Lime, Ambra) a 20 bit
    • CCT da 2.700 a 6.500 K con Indice di Resa Cromatica > 90
    • Dimmer elettronico a 16 bit con 4 curve selezionabili (esponenziale, logaritmica e lineare e halo) processate in digitale a 20 bit
    • Funzionamento flicker-free garantito (frequenza di aggiornamento LED a 20.000 Hz)
    • Lenti Fresnel e PC disponibili

    discover the product

next events

26. - 29. April 2022

Prolight + Sound 2022

Frankfurt am Main

Come and visit us in Frankfurt! Stand D73, Hall 12.1

OurWorld

Entertainment lighting since 1933</strong

In the year 1933, a small group of lighting engineers based in Milan, Italy, decided to form a company in order to create products for the performance industry. Through the years, Coemar has always taken the initiative to look beyond what is “available” and pursue the unimaginable. Proudly, Coemar accepts this role in the lighting society as the Artists of Lighting Technology.
